Widder 100 | Injector sandblasting cabin

Name: Widder 100 | Injector sandblasting cabin
SKU: 9411.100
Price: 3320.100001 EUR
Availability: InStock

€3,320.10 €2,790.00

Shipping not included

plus 19% VAT

Delivery time

approx. 2 - 3 weeks

We recommend the Widder 100 sandblasting cabin for sandblasting small parts. The equipment is fitted through a side door on the right-hand side. Sandblasting room dimensions (W x D x H): 1,000 x 600 x 600 mm.

Widder 100 | Injector sandblasting cabin is available to buy in increments of 1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

SAPI high-performance injector sandblasting cabin type "Widder 100"

The suction sandblasting cabin of the type "Widder 100" is a compact injector sandblasting cabin. The sandblasting cabin takes up little space and is easy to move using a lift truck or forklift.

Our high-performance injector sandblasting head creates high negative pressure and thus achieves a high blasting power, which enables fast, economical work with the negative pressure blasting cabin. The blasting nozzle is made of boron carbide and has an extremely long service life, even when using corundum blasting media.

To illuminate the blasting room, a modern, energy-saving LED light is attached to the cabin roof, protected from dust. This ensures optimal illumination of the blasting room of the blasting cabin and enables fast, fatigue-free and economical work.

Our sandblasting cabins are made of strong sheet steel, which enables the work grate to have a high load-bearing capacity.

All SAPI sandblasting cabins meet all current safety standards and are equipped with a door safety switch, which stops the sandblasting process immediately if the cabin is opened during the sandblasting process.

An additional extraction system is required for optimal operation of the sandblasting cabin. There are 3 different versions to choose from, depending on the purpose and duration of use.

The extraction system ensures optimal visibility in the sandblasting room, a dust-free work environment and is responsible for cleaning the sandblasting media used.

By using the right filter system, optimal abrasive cleaning is achieved in order to guarantee the maximum service life of the abrasive used.

Corundum, glass beads, plastic granules, vegetable granules, etc. can be used as blasting media.

Technical specifications:


Overall dimensions
Total height:	1.650 mm
Total width:	1.050 mm
Total depth:	800 mm
Dimensions of the sandblasting room area
Width:	1.000 mm
Depth:	600 mm
Height:	600 mm
Technical characteristics
Air consumption:	600 - 1.000 l/min.
Nozzle:	Ø 8 mm Boron carbide nozzle (optionally other diameters)
Air nozzle:	Ø 3,5 mm
Air pressure:	2 bis 12 bar
Load capacity:	ca. 150 kg
Electrical connection:	230 Volt / 50 Hz
Power consumption:	ca. 40 Watt
Color:	Grundkörper RAL 7035 lichtgrau Anbauteile RAL 7016 anthrazitgrau
Weight:	ca. 142 kg
Technical changes reserved!

Scope of delivery:

Sandblasting cabin "Widder 100"
Injector sandblasting head with boron carbide nozzle
Pressure regulator to adjust the sandblasting pressure with integrated water separator
LED lighting, attached to the cabin roof to protect it from dust
Door security switch
On/off footswitch
Rubber rosettes
1 pair of rubber gloves (emitter gloves)

Advantages of the SAPI high-performance injector sandblasting cabin:

Universally applicable blasting cabin for economical, highly efficient execution of all sandblasting work
Suitable for all common types of abrasive
generous, dust-proof side door for easy loading of the blasting cabin
Compact, portable design
Extremely bright, glare-free illumination of the blasting cabin interior with LED light
Extremely economical price/performance ratio
Movable with a pallet truck, wheelchair-accessible construction

Application areas:

Rust removal
Paint stripping
Descaling
Deburring
Hardening
Lapping
Glass bead rays
Aluminium and stainless steel processing
Roughening surfaces
Smoothing surfaces

Suitable abrasives:

Corundum
White Corundum
Ceramic beads
Glass beads
Broken glass
Silicon carbide
Garnet sand
Plastic abrasives
mineral reusable abrasives

Injector sandblasting cabins are not suitable for the use of metallic blasting media. A pressure sandblasting cabin is required for this.

More Information

More Information
SKU	9411.100
Delivery time	approx. 2 - 3 weeks
Shipping	Shipping not included
VAT	plus 19% VAT
Integrated filter	No
Door opening	Side door right
Max. Load capacity	150 kg
Cabin Type	Injector

Questions

Only registered users can write questions. Please Sign in or Create an account

Recommended accessories

Here you will find recommended accessories for the high-performance injector sandblasting cabin "Widder 100". This accessory makes it easier for you to work with the blasting cabin and increases its efficiency.

The following accessories are available:

Rubber lining for Widder 70: This prevents the sandblasting agent from crashing pointlessly on the cabin wall (up to 50% blasting agent savings). 9841.010
Air blow gun: For blowing dust off the sandblasted parts and the cabin walls. 3985.015

Special accessories

Here you will find special accessories for the high-performance injector sandblasting cabin "Widder 70". This can increase productivity and make work easier.

The following special accessories are available:

Swivel arm with sandblasting head holder: The sandblasting nozzle can be fixed in the sandblasting head holder. Thus, the worker has both hands free to hold and rotate the workpieces. The swivel arm can be adjusted and fixed in angle and inclination. 3944.020
Turntable ø 400 mm, manually operated: Enables the easier processing of heavy, unwieldy parts. The turntable is mobile and can be removed from the sandblasting room when it is not needed. Max. Load 40 kg. 9841.240
Rubber gloves permanently installed: The rubber gloves are connected directly to the cabin by means of a flange ring. 3941.135

Extraction systems

For the optimal, economical operation of the "Widder 100" sandblasting cabin, an extraction system is required, which ensures a negative pressure in the sandblasting room.

The filter system cleans the used sandblasting media and at the same time ensures a good view in the sandblasting room and a dust-free work environment.

Depending on the purpose and duration of use, different extraction systems are available:

"Turbo II" suction system For occasional spotlights, daily up to approx. 1 hour. 2-stage industrial vacuum cleaner, especially encapsulated and sealed with a 78 l stainless steel container. Equipped with 2 x 1080 watt turbines, which can be switched on separately. Exchangeable filter insert. 230 V / 50 Hz. 9341.020
Pocket filter suction system "TFA I" For daily sandblasting work between 1 - 4 hours. The compact filter system in a stable sheet steel housing. Pocket filter inserts with 4.5 m² filter surface. Air output 600 m³ / h, motor output 0.55 kW, power connection 400 V / 50 Hz. 3241.110
Cartridge filter "PC 1" For daily sandblasting work from 4 hours, also suitable for shift work. The compatible filter system in a stable radiant sheet housing. Filter cartridge with 10 m² filter surface and permanent cleaning using a compressed air blast. Air output approx. 900 m³ / h, motor output 0.55 kW, power connection 400 V / 50 Hz. 9311.010

We would be happy to advise you on the selection of the right extraction system, talk to us!
